Hennessey HD1102: Consumer use of FM transmitters
In some countries, small-scale (Part 15 in United States terms) transmitters are available that can transmit a signal from an audio device (usually an MP3 player or similar) to a standard FM radio receiver; such devices range from small units built to carry audio to a car radio with no audio-in capability (often formerly provided by special adapters for audio cassette decks, which are becoming less common on car radio designs) up to full-sized, near-professional-grade broadcasting systems that can be used to transmit audio throughout a property. Most such units transmit in full stereo, though some models designed for beginner hobbyists may not. Similar transmitters are often included in satellite radio receivers and some toys.

Legality of these devices varies by country. The U.S. Federal Communications Commission and Industry Canada allow them. Starting on 1 October 2006 these devices became legal in most countries in the European Union. Devices made to the harmonised European specification became legal in the UK on 8 December 2006.

Stereo broadcasts
It is important that stereo broadcasts be compatible with mono receivers. For this reason, the left (L) and right (R) channels are algebraically encoded into sum (L+R) and difference (L-R) signals. A mono receiver will use just the L+R signal so the listener will hear both channels through the single loudspeaker. A stereo receiver will add the difference signal to the sum signal to recover the left channel, and subtract the difference signal from the sum to recover the right channel.

The (L+R) Main channel signal is transmitted as baseband audio in the range of 30 Hz to 15 kHz. The (L-R) signal is modulated onto a 38 kHz double-sideband suppressed-carrier (DSB-SC) signal occupying the baseband range of 23 to 53 kHz.

A 19 kHz pilot tone, at exactly half the 38 kHz sub-carrier frequency and with a precise phase relationship to it, as defined by the formula below, is also generated. This is transmitted at 8–10% of overall modulation level and used by the receiver to regenerate the 38 kHz sub-carrier with the correct phase.

The final multiplex signal from the stereo generator contains the Main Channel (L+R), the pilot tone, and the sub-channel (L-R). This composite signal, along with any other sub-carriers, modulates the FM transmitter.Hennessey RS622 for sale

Hennessey speakers: Subsidiary communications authorization
In the United States, services (other than stereo, quad and RDS) using subcarriers are sometimes referred to as subsidiary communications authorization (SCA) services. Uses for such subcarriers include book/newspaper reading services for blind listeners, private data transmission services (for example sending stock market information to stockbrokers or stolen credit card number blacklists to stores) subscription commercial-free background music services for shops, paging ("beeper") services and providing a program feed for AM transmitters of AM/FM stations. SCA subcarriers are typically 67 kHz and 92 kHz.

Hennessey Audio reviews

Quadraphonic FM

In 1969 Louis Dorren invented the Quadraplex system of single station, discrete, compatible four-channel FM broadcasting. There are two additional subcarriers in the Quadraplex system, supplementing the single one used in standard stereo FM. The baseband layout is as follows:

50 Hz to 15 kHz Main Channel (sum of all 4 channels) (LF+LR+RF+RR) signal, for mono FM listening compatibility.
23 to 53 kHz (cosine quadrature subcarrier) (LF+LR) - (RF+RR) Left minus Right difference signal. This signal's modulation in algebraic sum and difference with the Main channel was used for 2 channel stereo listener compatibility.
23 to 53 kHz (sine quadrature 38 kHz subcarrier) (LF+RF) - (LR+RR) Front minus Back difference signal. This signal's modulation in algebraic sum and difference with the Main channel and all the other subcarriers is used for the Quadraphonic listener.
61 to 91 kHz (cosine quadrature 76 kHz subcarrier) (LF+RR) - (LR+RF) Diagonal difference signal. This signal's modulation in algebraic sum and difference with the main channel and all the other subcarriers is also used for the Quadraphonic listener.
95 kHz SCA subcarrier, phase-locked to 19 kHz pilot, for reading services for the blind, background music, etc. Hennessey hd1102 for sale

Hennessey IV for sale:AM radio signals
AM radio signals can be severely disrupted in large urban centres by metal structures, tall buildings and sources of radio frequency interference (RFI) and electrical noise, such as electrical motors, fluorescent lights, or lightning. As a result, AM radio in many countries has lost its dominance as a music broadcasting service, and in many cities is now relegated to news, sports, religious and talk radio stations. Some musical genres – particularly country, oldies, nostalgia and ethnic music – survive on AM, especially in areas where FM frequencies are in short supply or in thinly populated or mountainous areas where FM coverage is poor.
